Introduction
Like many other systems proposed in the literature, the closest ancestor in Sequent’s genealogy tree is Helios[1] in its original mixnet variant. The most significant departures from that Helios design are the use of a threshold distributed key generation mechanism, described in Pedersen[2] and featured in CGS[3] and Distributed Helios[4], and the use of a Terelius-Wikstrom[5] style mixnet rather than the Sako-Kilian[6] one. Other systems with which Sequent shares techniques are Wombat[7] and CHVote[8].
Research and development into Sequent’s next generation system is currently underway. Part of this effort has been centred around the use of Rust[9] as a core technology. One of the interesting aspects of this technology is its ability to target WebAssembly[10] through the LLVM[11] toolchain.
Internet voting systems require the use of a client component with which voters select and encrypt their votes, typically in a browser. In the past, these components have been written in Javascript or related languages. These components replicate some of the cryptography (for example, ElGamal encryption) that later processes votes in the backend. The initial motivating factor for our investigation of Rust’s WebAssembly target was the possibility of merging this overlapping cryptography into a single unified codebase. But there are further interesting possibilities.
Applications
Vote casting
Voting client software can reuse common cryptography packaged in a library compiled to Wasm, eliminating duplication.
Suggested benefits:
- Security: A unified code base reduces the likelihood of mismatches between client and server cryptography, and reduces the attack surface. The amount of code that needs to be audited is also reduced.
- Performance: Higher performance compared to Javascript implementations.
Ballot verification
Ballot verifiers implementing the Benaloh challenge can reuse common cryptography packaged in a library compiled to Wasm, eliminating duplication.
Suggested benefits: As above.
Election verification
Election verification, usually carried out by specialised software that must be downloaded and configured, can be executed in the browser with no installation.
Suggested benefits:
- Verifiability: Making election verification procedures significantly more usable can achieve higher rates of exercised verification, moving the “universal” part of universal verifiability closer to practice.
Note that achieving performant implementations in this use case is particularly difficult as election verification involves compute intensive operations that a priori seem impossible in a browser. We have not listed performance as a benefit here as we are comparing with non-browser, native implementations; in other words, performance is a must-have rather than a benefit for this use case.
Trustee protocols
Running full trustee nodes on the browser with reduced deployment, administration and training costs.
Suggested benefits:
Real world experience has taught us that one of the barriers to running mixnet-based elections with a larger number of independent trustees is the cost that these trustees must incur in terms of deployment, administration and training. This is especially true for elections with fewer resources in human capital and infrastructure. As a result, it is not always easy to procure independent trustees to assume this important responsibility.
Any objective that is presumably achieved through distribution into independent trustees could be achieved to a greater degree when some of the costs of this distribution are reduced. For example:
- Privacy: Ballot secrecy safeguards achieved through the distribution of private key material and mixing permutations would be achieved to a higher degree if more trustees participate.
- Security: Correctness safeguards achieved through distribution of mixing and tallying would be achieved to a higher degree if more trustees participate.
See previous section regarding performance as a benefit.
Demonstration
We choose to demonstrate the most complex scenario described above, as it’s a proof of concept that also validates the rest of the comparatively simpler use cases. We show how trustee operations, both shuffling and decryption, can be run in the browser. We will also show that the resulting performance numbers fall within the threshold of practical applicability in small to medium elections.
As stated previously, achieving performant mixing in the browser is a particularly difficult task: this requires cutting edge technology that is currently experimental. Additionally, the full security implications of applying these techniques have to be analysed in detail.
You can access the demo directly from your web browser here [12] ** and you can also see a video of how the demo performs running in the browser below:
Note
References
[1] Helios: Web-based Open-Audit Voting
[2] Non-interactive and information-theoretic secure verifiable secret sharing
[3] A secure and optimally efficient multi-authority election scheme
[4] Distributed ElGamal à la Pedersen: Application to Helios
[5] Proofs of Restricted Shuffles
[6] Receipt-free mix-type voting scheme — a practical solution to the implementation of a voting booth
[7a] Wombat Voting
[7b] An Implementation of Dual (Paper and Cryptographic) Voting System
[8] CHVote Protocol Specification
[9] https://www.rust-lang.org/
[10] https://webassembly.org/
[11] https://llvm.org/
[12] https://strand_github_pages.sequentech.io/demo.html
[13] https://dspace.ut.ee/handle/10062/84432 (page 175)
